SDN Nitrogen Dioxide Detector (NO2)
SDN Nitrogen Dioxide Detector (NO2)

SDN Nitrogen Dioxide Detector (NO2)

Brand: Golmar
Product Code: GO21122999

  • Nitrogen dioxide (NO2) particle-sensitive detector.
  • Certified according to UNE 23300 and EN 50545-1 standards
  • 10-year lifespan
  • Detection via electrochemical probe
  • Installation height: between 1.5 and 2m above ground level
  • Coverage area: 200 m²
  • Supply voltage: 24 to 35 V DC (with polarity)
  • Average power consumption during monitoring: 2 mA
  • Average power consumption during alarm: 4 mA
  • Status indicated by a red LED
  • Operating temperature: -10°C to 50°C
  • Relative humidity: 20 to 93%
  • Supplied without base
  • Dimensions: 115 (Ø) × 60 (H) mm
Brochure
Download Image

  • Recommended installation height: 1.5 to 2m above the ground.
  • Supplied without a base.
  • Status indicator: Red LED
  • Protected area: 200 m²
  • Supply voltage: 24 to 35 V (with polarity)
  • Monitoring current: 2 mA
  • Alarm current: 4 mA
  • Dimensions: Ø 115 x h 60 mm
  • Humidity: 20-95% RH
  • Temperature: -10°C ~ +50°C
  • IP 30
  • Lifespan: 4 years
